BEBMS-16S100A


Number of strings supported: 16
Battery type: lithium manganate, lithium ternary, lithium cobalate, lithium iron
Supporting current: 100A
Balanced: Yes
Size: 180 * 110 * 10mm
支持串数: 16 String
电池类型: Lithium manganese, lithium ternary, lithium cobalt, lithium iron
支持电流 : 100A
是否均衡: Yes
尺寸: 180*110*10mm

Details

Description:

TVS and built-in flood current diversion coppers for bms circuit board protection. MOS FET dual core protection.

● Management of 2 NTC temperature sensors
● Measurements accuracy:

Cell voltages: +/- 5 mV
Temperatures: +/- 1°C

Protection:

The BMS is designed to monitor the battery status and take appropriate actions to prevent or mitigate potential hazards. The following are the main protection functions of BMS for lithium batteries:

● Over charger and over-discharge function, when battery voltage it reaches the maximum and minimum safe level.
● Temperature protection: High temperature can accelerate the aging of the battery and increase the risk of thermal runaway. The BMS monitors the battery temperature and takes appropriate actions, such as reducing the charging/discharging current or stopping the operation, to prevent overheating.
● Over-current protection: Over-current can damage the battery and cause safety hazards. The BMS monitors the current flow and stops the operation when it exceeds the maximum safe level.
● Short circuit protection: Short circuit can cause a high current flow and generate heat, which may lead to an explosion or fire. The BMS monitors the circuit and disconnects it when a short circuit is detected.

Power supply/consumption:

Supply of the BMS directly on the battery pack
Low consumption in sleep mode: < 500 μA

Mechanical format:

66 mm x 155 mm x 22 mm
Can be potted to be used in harsh environment.
